Replacement tank LRA 150L Nissan Navara D40 Spanish

The replacement tank LRA is designed for the Nissan Navara D40 diesel 4WD, Spanish model, Dual body style, from 2005 to 2015. With its capacity to 150 litersIt replaces the original tank to increase fuel range for travel, tracks, raids and travel in isolated areas.

This tank is installed on the left side of the driveshaft, retaining the standard exhaust and original filler point. The spare tire remains in place. The instructions describe removing the standard tank, reusing the original fuel gauge and strainer, extending the float arm by 60 mm and the quick-release vent tube, extending the fuel gauge wires by 200 mm, and refitting the standard tank's heat shield onto the new tank. If a flatbed truck bed is fitted, refueling may require modification and additional labor time.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Replacement tank
- Capacity: 150 liters
- Vehicle compatibility: Nissan Navara D40 Spanish 2005 to 2015
- Compatible engine type: Diesel
- Bodywork: Dual
- Transmission: 4WD
- Tank replaced: Original tank
- Position: Left side of the driveshaft
- Exhaust: Standard
- Filling point: Standard
- Gauge: Original gauge reused, float arm to be extended by 60 mm
- Spare wheel: Retained
- Estimated assembly time: 3 hours
- Made in Australia
